ASTM D 4304 Type I & II
China National Standard GB 11120-2011 L-TSA
DIN 51515 Part I & II
ISO 6743-5 TSA, TSE, TGA, TGB, TGE, TGSB, TGSE
ISO 8068
JIS K-2213 Type 2
Approvals (Selection)
Alstom HTGD 90117, Ansaldo TG02-0171, Baker Hughes ITN 52220.01/02/03/06, Doosan Skoda
General Electric GEK 28143, 32568, 27070, 46506, 107395, 101941
Siemens Industrial Turbo AB MAT 812101/02/06/07/08/09
Siemens TLV 901304, TLV 901305
Siemens Turbomachinery 1CW0047915
Solar ES 9-224 W Class II
Typical Properties
Density at 15 °C: 841 kg/m³
Viscosity at 40 °C: 32 mm²/s
Viscosity at 100 °C: 5.7 mm²/s
Viscosity index: 107
Flash point: 225 °C
Pour point: –30 °C
Foaming Seq.1 (24 °C): 10/0 ml/ml
Foaming Seq.2 (24 °C): 10/0 ml/ml
Foaming Seq.3 (24 °C): 10/0 ml/ml
Air release (50 °C): 2.5 min
Water separation (55 °C): 4 min
TOST (ASTM D 943): >10,000 h
RPVOT (ASTM D 2272): 2,000 min
FZG (A/8.3/90): Stage ≥9
